LDPE Pipe Winding Machine 6 Claw For Plastic Pipe Making Industry
1,Machine Introduction:
The auomatic coil winding machine is mainly suitable for plastic HDPE/ PE pipe, PP pipe, PPR pipe, PVC pipe, plastic single wall corrugated pipe, plastic aluminum pipe, and small size hose. It is usually applied in the pipe production line. We have single-station (single-plate) and double-station (double-plate) plastic pipe automatic coil winding machine.
2,Features and Advantages
1. The automatic coil winding machine adopts automatically winding, adjusting winding speed and winding method. Its has two disks for continuous winding.
2. The plate of this automatic coil winding machine is controlled by gas, winding adopt torque motor, with special equipment to arrange the pipe, this pipe winding machine can wind pipe well and working very stable.
3. The design has chute, the leaf can also slide in the chute, the coil diamter can be adjusted.
4. There are mainly model for HDPE/PE/PP/PPR/PVC hose pipe winding: 16-40mm single/double plate pipe winding machine, 16-63mm single/double plate pipe wiinding machine, 50-110mm single/double plate winding machine; 20-110mm double plate winding machine, 50-160mm single plate winding machine.
5. We can also design and make it according to your request.
Pipe Winding Machine Parameters |
| Model | QP32 | QP75 |
| Inner diameter | 340-800 MM | 1000-2200 MM |
| Max Winding Outer Diameter (mm) | 1200 | 2400 |
| Winding Width (mm) | 300-400/400-500 | 400-500/500-600 |
| Max Winding Pipe (mm) | 16-32 | 75-110 |
| Power Torque Motor | 10NM | 40NM |
| Rolling Ring Drive | GP30 | GP40 |
| Winding Speed | 0.5-40m/min | 0.5-40m/min |
| Slowing Speed Machine | WPA80 | WPA120 |
| Rewinding Claw(number) | 6 | 6 |
| Single-Station/Head | 1.9*1.5*1.5 M(200KG) | 4*2.8*2.8 M |
| Double-Station | 2.8*1.6*2 M (300KG) Same direction | 6*2.8*2.8 Indirectional |
Business Scope:
Our company mainly products roller guides ,rolling ring drives ,wire take up machine, wire coil winding machine ,pipe winding machine, automatic coiling and packaging machine, microcomputer automatic rolled plate machine ,wire straightener , wire straightening and cutting machine, etc. (Some as follow picture show)
After-sales service:
After the sale, the machine is guaranteed for one year under the premise of reasonable use of the customer. Maintain work at home and maintain response time of no more than 24 hours. Free maintenance during the warranty period, and the equipment maintenance service beyond the warranty period is subject to clear charges.
Company Profile:
The company’s production has evolved from the production of single-ring rolling mills and steel wire roller devices to large-scale machinery such as cable winding machines, coil winding machines, small spool winding machines, textile yarn winding machines, and microcomputer coil winding Line packaging machine etc. This series is equipped with advanced production equipment, and the company has become a well-known professional equipment manufacturer in the industry.
FAQ:
Q: What we can do for you?
A: We provide wire straightener,traverse linear,winding machine, we can aslo provide Production line scheme,such as wire/cable extrusion line.
Q: What is your delivery date?
A: The delivery date is about 3-25 working days after receive the payment.
Q: What is your payment terms?
A: TT 100% payment in advance.
Q:This machine is easy to use ? if I have no experience, I can also operate it well ?
A:Yes, our machine is designed to use easily, Normally it will take you 1 day to learn how to operate, if you areatechnician, it will much faster to learn.
Q:Do you provide the user manual and operating videos to support us ?
A:We will provide the English user manual for free , and the operation video is available. Our software is all English.
